Yamaha DTX6K5-M 5-Piece Electronic Drum Set With DTX-PRO(Yamaha Dtx6k5 M 5 Piece Electronic Drum Set With Dtx Pro)

Yamaha DTX6K5-M 5-Piece Electronic Drum Set with DTX-PRO

Experience the next level of electronic drumming with the Yamaha DTX6K5-M Electronic Drum Set. This advanced kit is designed for drummers seeking a realistic feel and versatile sound options. With the Firmware Version 2 update, you can choose from 70 preset studio-sampled drum kits or create up to 200 custom kits using the DTX6K5-M's extensive library of over 700 voices. Whether you're practicing at home or performing on stage, this drum set delivers exceptional performance and adaptability.

The DTX6K5-M features high-quality mesh pads that provide a natural rebound and quiet operation, making it ideal for both practice and live settings. The 12-inch XP120L-M snare and 10-inch XP100L-M tom pads offer dual-zone triggering, allowing for expressive playability. The KP90 kick pad with its 7.5-inch rubber surface and multi-layer cushion ensures a realistic bass drum feel, accommodating both single and double pedal setups.

Enhance your playing experience with the included RHH135 13-inch hi-hat pad, which mounts on the HS650A hi-hat stand for authentic hi-hat control. The kit also includes two 13-inch PCY135 crash cymbal pads and a 15-inch PCY155 ride cymbal pad, all featuring three-zone triggering for a wide range of cymbal sounds and techniques. The compact footprint of approximately 43.3 inches by 55.1 inches makes it suitable for various spaces without compromising playability.

Key Features

• Firmware Version 2 update with 70 preset studio-sampled drum kits
• Capability to create up to 200 custom kits using over 700 voices
• High-quality mesh pads for realistic feel and quiet operation
• Dual-zone snare and tom pads for expressive playability
• Authentic hi-hat control with RHH135 pad and HS650A stand
• Three-zone cymbal pads for versatile cymbal techniques
• Compact footprint suitable for various spaces

Technical Specifications

Pad Sets

• Snare: XP120L-M (12-inch mesh pad with 2 zones)
• Tom Pads: XP100L-M (10-inch mesh pads with 2 zones)
• Floor Tom Pad: XP100L-M (10-inch mesh pad with 2 zones)
• Kick Pad: KP90 (7.5-inch rubber pad with multi-layer cushion)
• Hi-Hat Pad: RHH135 (13-inch pad with 2 zones)
• Crash Cymbal 1: PCY135 (13-inch pad with 3 zones)
• Crash Cymbal 2: PCY135 (13-inch pad with 3 zones)
• Ride Cymbal: PCY155 (15-inch pad with 3 zones)

Hi-Hat Stand: HS650A

Footprint (Average): 43.3" x 55.1"

Weight: 70.9 lbs

Tone Generator

• Dimensions: 11-15/16" (W) x 7-11/16" (H) x 2-5/8" (D)
• Weight: 3 lbs 5 oz
• Maximum Polyphony: 256 notes
• Effects: EQ, Compression, Transient, Insertion for each instrument; Ambience, Effect 1, Effect 2, Master Compression, Master Effect for each kit; Master EQ, Phones EQ
• Drum Kits: 40 preset kits, 200 user kits
• Voices: 712

Click

• Click Sets: 30
• Tempo: 30 to 300 BPM, Tap tempo supported
• Time Signatures: 1/4 to 16/4, 1/8 to 16/8, 1/16 to 16/16
• Subdivisions: Accents, quarter notes, eighth notes, sixteenth notes, eighth-note triplets
• Other: Individual click volume control, WAV import, timer

Training

• Types: 10
• Songs: 37 preset songs, 1 user song

Audio Files

• Import Limit: 1,000 files
• Maximum Loadable Sample Time: 760 seconds (44.1 kHz, 16-bit, mono); 380 seconds (44.1 kHz, 16-bit, stereo)
• Sample Format: WAV

Recorder

• Recording Time: Up to 90 seconds in internal memory; up to 90 minutes per file on USB flash drive
• Format: Record/playback in WAV (44.1 kHz, 16-bit, stereo)

Other

• Connectors: DC IN (+12V); Headphones (standard stereo phone jack); AUX IN (stereo mini jack); OUTPUT L/MONO, R (standard phone jack); USB TO DEVICE; USB TO HOST; MIDI OUT; Trigger inputs
• Display: Full Dot LCD (128×64 dot)
• Accessories: AC adapter (PA-150 or equivalent), Owner’s Manual, module holder, module holder wing bolts (x4), Cubase AI Download Information
